Overview
A ring wave generator is used to evaluate the performance of electrical and electronic equipment, devices or systems subjected to ring wave. Ring wave is caused by power supply and control line switches or lightning strike and appears on the terminal of devices. The ring wave may affect the reliable operation of equipment and system. Product can meet the requirements of standard IEC 61000-4-12 & GB/T 17626.12.
Features
● User friendly 7" touch panel display
● Support multi-language & facilitate users
● Built-in environment self-test program
● Programmable operation
● Pre-programed international standard test level parameters, easy to operate
● RS232/USB interface, PC control operation & printable test report
Ring Wave Generator Technical Data
|
Model |
RWI T6 |
|
|
Output voltage |
0.2~6kV |
|
|
Oscillation frequency |
100kHz |
|
|
Polarity |
Positive/negative/alternating |
|
|
Impedance |
12Ω, 30Ω, 200Ω |
|
|
Rise time |
Current rise time≤1μs, voltage rise time≤ 0.5μs ±20% |
|
|
Pulse repetition |
1/10s (1~60 transients per minute) |
|
|
Pulse interval |
10~9999s |
|
|
Number of pulses |
1~9999 |
|
|
Phase |
0~359°synchronous, asynchronous, automatic |
|
|
Coupling/decoupling network |
External, 3-phase 5-line, 16A (custom specific on demand) |
|
|
Power supply |
AC220V 50/60Hz |
|
|
Ambient temperature |
15℃~35℃ |
|
